Transaction Webhook Payload

When configuring your Callback URL, you will need to specify whether your endpoint expects to receive HTTP GET or HTTP POST requests.

Subsequently, when an event occurs (such as a transaction status update), IIMMPACT will send an HTTP request using your chosen method.

Below is an illustrative example of the data sent in a callback:

IP Allowlist

For these callbacks to reach your system successfully, add the IP addresses for your environment to your allowlist. If you use staging, allowlist the staging IP address together with both production IP addresses.

Environment	IP Addresses
Production	18.140.170.98, 13.215.6.214
Staging	3.1.120.89, 18.140.170.98, 13.215.6.214

Callback Payload

Field	Type	Description
data.statusCode	number	Status code — see Payment Errors
data.status	string	Outcome: Processing, Succesful, or Failed
data.account	string	Account number
data.product	string	Product code
data.productName	string	Customer-facing product name (e.g. "Celcom Prepaid"). Empty string if unavailable
data.amount	number	Amount paid
data.sn	string	Serial number from the provider/operator
data.pin	string	PIN for vouchers, gift cards, etc.
data.expiry	string	Expiration date of the voucher (yyyymmdd). Empty string if not applicable
data.cost	number	Your wholesale cost for this transaction (deducted from your IIMMPACT wallet balance).
data.balance	number	Your current wallet balance after this transaction
data.remarks	string	Additional notes about the transaction
data.refid	string	Your unique reference ID
data.timestamp	string	Transaction timestamp
data.note	string	Instructions or information for the user regarding the product
data.voucherlink	string	Link to access or redeem the voucher

Sample HTTP POST Callback

{
  "data": {
    "statusCode": 20,
    "status": "Succesful",
    "account": "0123456789",
    "product": "GC",
    "productName": "Grab Gift Code",
    "amount": 5,
    "sn": "106648697",
    "pin": "MPHE39G3WL",
    "expiry": "20251116",
    "cost": 5,
    "balance": 50.54,
    "remarks": "",
    "refid": "321479-0-30f4f209-ee",
    "timestamp": "2025-05-20 13:09:34",
    "note": "Insert voucher code into Use Grab Gifts under Use Offers section upon check out",
    "voucherlink": "https://api.grab.com/gifts/v2/go?id=7464957319334bb0afbd5980738a2b50"
  }
}

Sample HTTP GET Callback

The GET callback sends four top-level query parameters: refid, status (status code), price, and message (URL-encoded JSON containing the full transaction data).

GET Parameter Mapping

The GET callback uses different parameter names than the POST payload. Use this mapping:

GET Query Parameter	Maps To	Type	Note
refid	refid	string	Reference ID (same name)
status	statusCode	number	Not the status string — this is the numeric status code
price	cost	number	Your wholesale cost (not the face value)
message	Full response	URL-encoded JSON	Decode with decodeURIComponent() to get all transaction fields

Recommendation

Use POST callbacks instead of GET. POST delivers the full transaction payload as structured JSON in the request body, avoiding URL encoding issues and parameter name confusion.

https://yourdomain.com?refid=1234t&status=48&price=9.73&message=%7B%22statusCode%22%3A48%2C%22status%22%3A%22Failed%22%2C%22account%22%3A%220123456789%22%2C%22product%22%3A%22C%22%2C%22productName%22%3A%22Celcom+Prepaid%22%2C%22amount%22%3A10%2C%22sn%22%3A%22%22%2C%22pin%22%3A%22%22%2C%22expiry%22%3A%22%22%2C%22cost%22%3A9.73%2C%22balance%22%3A50.54%2C%22remarks%22%3A%22HC%22%2C%22refid%22%3A%221234t%22%2C%22timestamp%22%3A%222025-05-21+14%3A29%3A31.710%22%2C%22note%22%3A%22%22%2C%22voucherlink%22%3A%22%22%7D

Decoded message parameter:

{
  "statusCode": 48,
  "status": "Failed",
  "account": "0123456789",
  "product": "C",
  "productName": "Celcom Prepaid",
  "amount": 10,
  "sn": "",
  "pin": "",
  "expiry": "",
  "cost": 9.73,
  "balance": 50.54,
  "remarks": "HC",
  "refid": "1234t",
  "timestamp": "2025-05-21 14:29:31.710",
  "note": "",
  "voucherlink": ""
}

Verifying Callback Authenticity

Transaction callbacks do not currently include a cryptographic signature. HMAC signature verification is planned for a future release.

In the meantime, use these verification steps:

1. IP Allowlist — Only accept callbacks from IIMMPACT's IP addresses (listed above). Reject requests from unknown IPs.
2. Match refid — Verify that the refid in the callback matches a transaction you initiated. Reject callbacks for unknown reference IDs.
3. Validate fields — Check that product, account, and amount match your original request.
4. Re-query for confirmation — For high-value transactions, call POST /v2/topup with the same refid to independently verify the transaction status.
5. Idempotent handling — Process each refid only once. Ignore duplicate callbacks for the same transaction.

Retry Behavior

If your endpoint fails to respond successfully, IIMMPACT retries transaction callbacks up to 3 times with a 60-second delay between attempts.

Setting	Value
Timeout	30 seconds per request
Retry limit	3 retries
Retry delay	60 seconds between attempts

Response	Retried?	Reason
5xx server error	Yes	Transient failure
408 request timeout	Yes	Transient failure
429 too many requests	Yes	Rate limited
Connection error / DNS failure	Yes	Network issue
4xx except 408 and 429	No	Permanent failure

Permanent Failures

4xx responses, except 408 and 429, are treated as permanent failures and are not retried. Ensure your endpoint returns 2xx after accepting a valid callback.
